RBA-18-AD6
The 19 inch wall cabinet RBA-18-AD6 is a two-piece (swiveling) welded 19" data and telecommunications cabinet with protection degree IP30 and load capacity 30 kg.
Dimensions: 18 U, 615 depth. With glass door.
The version has break-out openings in the roof and bottom of the housing for the use of fans.
The all-purpose 19" wall-mounted rack has a robust welded construction, high quality workmanship and state-of-the-art technology to ensure its professional look.The wall cabinet comes as standard with a 4-mm full glass door.
The integrated hinge system allows the door to be opened by almost 180°.
The RMA cabinet offers easy dismantling of the doors and replacement of the door stop. The locks of the door and the swiveling part are identical.
The vertical 19" rack rails are infinitely adjustable in the cabinet depth, which facilitates installation of the components and cable management.
In the upper, lower and rear part of the housing are
cable entries, which are provided with
breakable veneers. They can be sealed with the brush strip against dust. A plastic frame
protects the cables from damage.
All removable parts are interconnected and grounded to the appropriate standard requirements.
Attention: Article is delivered by forwarding agency.
Inclusive:
- 2 x door key
- 4 x wood screw 6x50
- 4 x washer 6,6
- 4 x dowels 10
- 8 x cage nut M6
- 1 x brush strip
Specials
-
19-inch wall-mounted cabinet, swiveling (two-part) with protection degree IP30
-
18 U
-
Depth 615 mm with glass door (safety glass, hardened 4 mm)
-
Fix the housing directly to the wall
-
Adjustable vertical rails
-
Robust welded steel construction
-
Ideal for the installation of data and telecommunication systems as well as distribution systems
-
Ground wire
-
Breakable openings for the use of fans
- Cable entries with break-out covers
Technical Details
| Dimension A (height rear side) |
900 mm |
| Dimension B (height front) |
795 mm |
| Dimension C (width front) |
516 mm |
| Dimension D (width rear side) |
600 mm |
| Dimension E (depth) |
615 mm |
| Dimension R1 |
854 mm |
| Dimension R2 |
420 mm |
| Gross weight |
33.6 kg |
| Net weight |
33.2 kg |
| Protection class |
IP30 |
| Recommended maximum load |
30 kg |
